LM G Series Laser Rangefinders

Golf rangefinder has flagpole lock, golf trajectory compensation, continuous measurement, distance/angle/height/speed measurement and vibration hint functions. It can be used in golf, power equipment installation, highway, municipal engineering, forestry survey and design, construction, network planning and communication maintenance.

Models in LM600G Series: LM600G, LM800G, LM1000G, LM1200G, LM1500G

Contact

SKU: N/A Category: Laser Rangefinders

Description

Description

Features

Features of LM600G Series Golf Rangefinders

Certificates: CE, RoHS

● Durable Body
● High precision
● 6 x optical
● Harmless laser

● Vibration hint

● Lithium battery
● Golf mode
● Flagpole lock mode
● Ultra Clear LCD Display

● ±6°diopter

Specifications

Specifications of LM600G Series Golf Rangefinders

Specifications	LM600G	LM800G	LM1000G	LM1200G	LM1500G
Distance range	3-600m	3-800m	3-1000m	3-1200m	3-1500m
Accuracy	±1m ± range x 0.2%
Magnification	6X
Diopter adjustment range	±6°
Height	250m	300m	450m	500m	600m
Height error	±0.5m
Speed range	0-300Km/h
Angle	±60°
Objective aperture	19mm
Eyepiece aperture	15mm
Exit pupil diameter	3.7mm
Angle error	±1°
Flagpole lock	√
Golf trajectory compensation mode	√
Slope measurement	√
Height measurement	√
Auto power off	√
Laser class	Class 1
Laser wavelength	905nm
Operating temperature	-10℃~50℃
General Characteristics
Battery	3.7V 750mAh lithium battery
Product color	Black + silver
Product net weight	2.3g
Product size	108×68×38mm
Standard accessories	USB cable
Standard individual packing	Gift box、English manual、Carrying bag 、Hand strap
Standard quantity per carton	5 pcs
Gross weight(one carton)	2.6g

Applications

Applications of LM G Series Laser Rangefinders

The LM G Series can be used in golf, power equipment installation, highway, municipal engineering, forestry survey and design, construction, network planning and communication maintenance.
