LM-I Series Laser Distance Meters (Discontinued)
The LM series laser distance meters are portable devices that can easily and accurately measure length, area, and volumeby pressing one button. These tools can be used in interior/exterior design, construction, factory supervision, engineeringinspection, traffic accident evidence gathering, real estate development, fire assessment, and more.
Models in LM-I Series: LM60-I, LM80-I, LM100-I
Description
Features of LM-I Series Laser Distance Meters
Certificates: CE, UKCA
● Ergonomic exterior, comfortable handling
● Millimeter accuracy
● Large, multiple angle HD display
● Quick, auto calculation with real-time readout
● Physical leveler
● Auto power off after 3 minutes without operation
Specifications of LM-I Series Laser Distance Meters
| Specifications | LM60-I | LM80-I | LM100-I |
| Display type | EBTN | TN | |
| Display size | 2.0-inches | ||
| Range | 60m | 80m | 100m |
| Min. display unit | 0.001m | ||
| Measurement units | m/ft/in | ||
| Measurement basis | front/rear | ||
| Accuracy | ±(2mm+5 x 10-5D) | ||
| Laser class | 2 | ||
| Laser type | 630~670nm, ﹤1mW | ||
| Features | |||
| Volume/Pythagoras | √ | ||
| Add/Subtract | √ | ||
| Auto leveling horizontal/vertical | √ | ||
| Tilt angle | ±90.0° | ||
| Data storage | 20 groups | ||
| Auto laser off | 30s without operation | ||
| Auto backlight off | 10s without operation | ||
| Audio indication | √ | ||
| Battery status display | √ | ||
| General Characterisitics | |||
| Power | 1.5V battery (LR03) x 2 | ||
| Product color | Red and grey | ||
| Product net weight | 108.8g | ||
| Product size | 122mm x 52mm x 29.5mm | ||
| Standard accessories | Carrying bag | ||
| Standard individual packing | Gift box, English manual | ||
| Standard quantity per carton | LM40-I/50-I/60-I/80-I: 60pcs; LM100-I/120-I/150-I: 20pcs | ||
| Standard carton measurement | LM40-I/50-I/60-I/80-I: 520mm x 470mm x 345mm; LM100-I/120-I/150-I: 355mm x 340mm x 255mm | ||
| Standard carton gross weight | LM40-I/50-I/60-I/80-I: 15.3kg; LM100-I/120-I/150-I: 5.2kg | ||
Applications of LM-I Series Laser Distance Meters
These tools can be used in interior/exterior design, construction, factory supervision, engineeringinspection, traffic accident evidence gathering, real estate development, fire assessment, and more.
