UT658B USB Tester

UT658B USB tester is used to inspect USB charger and portable power source of electronics products. UT658B can output voltage, current, and power. Users can use this device to monitor charging status of any USB powered device.



Features of UT658B USB Tester

Certifications: CE, UKCA

● Charger capacity test (continuous memory)

● Charging voltage, current and battery capacity co-display

Specifications of UT658B USB Tester

Specifications UT658B
Input voltage range (V) 3V~9V
Voltage resolution 0.01V
Voltage monitoring accuracy ±(1%+5)
Current monitoring range (A) 0A~3.5A
Current monitoring accuracy ±(1%±5)
Current resolution 0.01A
Capacity 0~9999mAH
Capacity data storage 10 sets
Display LCD
Cable length 10cm
Pollution level 2
Working temperature  -10℃~40℃
Storage temperature  -10℃~50℃
Relative humidity <75%
General Characteristics
Product color White
Product net weight 30g
Product size 72mm x 29mm x 12mm
Standard individual packing Gift box
Standard quantity per carton 60pcs
Standard carton measurement 205mm x 170mm x 170mm
Standard carton gross weight 2.3kg

Applications of UT658B USB Tester

UT658B application 1
UT658B application 2
